Analog Mixers

Fill Your Space with Premium Sound

MGP / MG mixing consoles feature studio-quality preamps, powerful digital processing, and a rugged, reliable construction. They can easily adapt to a truly impressive range of applications from live performance, party with DJ, corporate events to fixed installation.

Model MGP Series MG Series (XU Model) MG Series (Standard Model)
D-PRE (Discrete Class-A Mic Preamps) Yes Yes Yes
1-knob COMP Yes Yes Yes
X-pressive EQ Yes No No
Digital Effects Yes (REV-X + SPX) Yes (SPX) No
APP MGP Editor MG Rec/Play, Cubase AI & Cubasis LE No
USB Interface Yes Yes No

Key Features

Yamaha's studio-grade discrete class-A D-PRE preamps

D-PRE preamps deliver fat, natural sounding bass and smooth, soaring highs, with very low distortion. They utilize an inverted Darlington circuit comprising two cascading transistors in a configuration that provides more power with lower impedance. D-PRE preamps possess an impressively wide frequency range without overly amplifying any specific elements of the sound.

A variety of input / output connectors

Switchable Phantom Power & PAD Switch

AUX / Effect Sends / Group

SPX Digital Effects / REV-X Reverb

MGP / MG XU models feature Yamaha's acclaimed SPX digital multi-effect processor, offering a comprehensive suite of editable digital effects perfect for enhancing your mix with remarkable realism and naturalness. On top of that, MGP series also feature high-end REV-X reverb offers high-resolution reverb effects: Hall, Room and Plate. Both processors can be used simultaneously.

1-Knob Compressors

Hybrid Channel (MGP Series)

CUBASE AI Bundled (MG XU series)

MG XU models are bundled with Downloadable Steinberg’s Cubase AI software. As one of the most advanced, comprehensive DAW suites available, Steinberg's Cubase has led the charge, providing users with a powerful and flexible platform for music production. Cubase AI offers these same core technologies and interface that have won Cubase worldwide acclaim. (* MG10XU MG12XU MG16XU MG20XU)

USB Audio Interface Function

(MGP Series / MG Series -XU Model-)

USB Device Recording and PlayBack

(MGP32X / MGP24X)

Lineup

Model MGP Series

MGP32X

MGP24X

MGP16X

MGP12X
Line Input 32 (24 mono + 4 stereo) 24 (16 mono + 4 stereo) 16 (8 mono + 4 stereo) 12 (4 mono + 4 stereo)
Mic Input 24 16 10 6
Aux Send 6 AUX Sends + 2 FX Sends 6 AUX Sends + 2 FX Sends 2 AUX Sends + 2 FX Sends 2 AUX Sends + 2 FX Sends
Group Out 4 Group Buses + ST Bus 4 Group Buses + ST Bus 4 Group Buses + ST Bus 4 Group Buses + ST Bus
USB IN/OUT USB Device, iPod/iPhone USB Device, iPod/iPhone iPod/iPhone only iPod/iPhone only
Digital Effects 8 REV-X + 16 SPX 8 REV-X + 16 SPX 8 REV-X + 16 SPX 8 REV-X + 16 SPX
USB Rec/Play (WAV/MP3) Yes Yes No No
Dimensions (W x H x D) 1,027 x 169 x 565mm (40.4" x 6.7" x 22.2") 819 x 169 x 565mm (32.2" x 6.7" x 22.2") 495 x 143 x 447mm (19.5" x 5.6" x 17.6") 495 x 143 x 348mm (19.5" x 5.6" x 13.7")
Net Weight 19.0kg (41.9lb) 15.5kg (34.2lb) 9.0kg (19.8lb) 7.5kg (16.5lb)
Model MG Series (XU Model)

MG20XU

MG16XU

MG12XU

MG10XU

MG06X
Line Input 20 (12 mono + 4 stereo) 16 (8 mono + 4 stereo) 12 (4 mono + 4 stereo) 10 (4 mono + 3 stereo) 6 (2 mono + 2 stereo)
Mic Input 16 10 6 4 2
Aux Send 4 (incl.FX) 4 (incl.FX) 2 (incl.FX) 1 (incl.FX) 0
Group Out 4 4 2 0 0
USB IN/OUT Yes (2 In / 2 Out) Yes (2 In / 2 Out) Yes (2 In / 2 Out) Yes (2 In / 2 Out) No
1-Knob Comp Yes Yes Yes Yes No
SPX Digital Effects 24 24 24 24 6
Cubase AI & Cubasis LE Yes Yes Yes Yes No
MG Rec/Play Yes Yes Yes Yes No
Dimensions (W x H x D) 444 x 130 x 500mm (17.5" x 5.1" x 19.7") 444 x 130 x 500mm (17.5" x 5.1" x 19.7") 308 x 118 x 442mm (12.1" x 4.6" x 16.6") 244 x 71 x 294mm (9.6" x 2.8" x 11.6") 149 x 62 x 202mm (5.9" x 2.4" x 7.9")
Net Weight 7.1kg (15.7lb) 10.5kg (23.2lb) 4.2kg (9.3lb) 2.1kg (4.63lb) 0.9kg (1.98lb)
Model MG Series (Standard Model)

MG20

MG16

MG12

MG10

MG06
Line Input 20 (12 mono + 4 stereo) 16 (8 mono + 4 stereo) 12 (4 mono + 4 stereo) 10 (4 mono + 3 stereo) 6 (2 mono + 2 stereo)
Mic Input 16 10 6 4 2
Aux Send 4 4 2 1 0
Group Out 4 4 2 0 0
USB IN/OUT Yes (2 In / 2 Out) Yes (2 In / 2 Out) Yes (2 In / 2 Out) Yes (2 In / 2 Out) No
1-Knob Comp Yes Yes Yes Yes No
Dimensions (W x H x D) 444 x 130 x 500mm (17.5" x 5.1" x 19.7") 444 x 130 x 500mm (17.5" x 5.1" x 19.7") 308 x 118 x 442mm (12.1" x 4.6" x 16.6") 244 x 71 x 294mm (9.6" x 2.8" x 11.6") 149 x 62 x 202mm (5.9" x 2.4" x 7.9")
Net Weight 6.9kg (15.2lb) 6.6kg (14.6lb) 4.0kg (8.8lb) 1.9kg (4.19lb) 0.9kg (1.98lb)
